Dayton Audio's compact ND65-8 aluminum cone driver demonstrates the latest advances in... more
Product information "Dayton Audio ND65-8"
Dayton Audio's compact ND65-8 aluminum cone driver demonstrates the latest advances in high-excursion design processes.
An efficient, low-distortion Neo-Balanced motor is combined with a rigid yet lightweight aluminum diaphragm, yielding impressive high-impact audio reproduction. Perfect for single point-source speaker applications, or combined in multiples and line arrays.
Product Highlights
• Rubber-edged aluminum alloy cone
• Large excursion capability
• Self-shielded Neo-Balanced motor structure
• 4-layer underhung voice coil with polyimide former
• High power handling
ND65-8 Specifications
Impedance 8 ohms
Re 7.4 ohms
Le 1.04 mH @ 1 kHz
Fs 77.4 Hz
Qms 4.01
Qes 0.46
Qts 0.41
Mms 2.5g
Cms 1.68 mm/N
Sd 15.6 cm²
Vd 5.4 cm³
BL 4.47 Tm
Vas 0.71 liters
Xmax 3.5 mm
VC Diameter 19 mm
SPL 80.8 dB @ 2.83V/1m
RMS Power Handling 15 watts
Usable Frequency Range (Hz) 80 - 20,000 Hz
