Vifa NE85-W-04

Vifa NE85-W-04 2.5" Fullrange

Vifa's NE Series full-range drivers feature an innovative sculpted, open cast aluminum basket design that minimizes internal acoustic reflections and acts as the neodymium motor's heatsink. The cone is aluminum, with a butyl rubber surround designed by finite element analysis for linearity of performance. FEA techniques also contribute to the motor's copper cap, which reduces inductance and extends high frequency performance.

Specifications:

*Power handling: 20 watts RMS/40 watts max

*VCdia: 25mm

*Le: 0.04 mH

*Impedance: 4 ohms

*Re: 3.5 ohms

*Frequency range: 100-20,000 Hz

*Fs: 167 Hz

*SPL: 84.8 2.83V/1m

*Vas: 0.17 l.

*Qms: 5.3

*Qes: 0.74

*Qts: 0.65

*Xmax: 1.75 mm

• Cast aluminum frame acts as a heatsink
• Sculpted design promotes cooling and reduces reflections
• High-strength compact neodymium motor
• Aluminum cone with half-roll rubber surround
• Long-throw voice coil on titanium former
• Copper pole piece cap for extended HF response
• 4 ohm nominal impedance
