- Order number: tbW8-670c
Tangband W8-670C utilizes a heavy-duty paper cone, foam surround, and bumped back plate for... more
Product information "Tangband W8-670C"
Tangband W8-670C utilizes a heavy-duty paper cone, foam surround, and bumped back plate for maximum mechanical movement. The 50 mm (2 inch) 4-layer voice coil, vented pole piece, and heavy-duty aluminum voice coil former provide impressive power handling. Excellent for small-enclosure stereo or home cinema.
DIAPHRAGM MTL | Paper |
SURROUND MTL | Foam |
NOMINAL IMPEDANCE | 8 Ohm |
DCR IMPEDANCE | 6.5 Ohm |
SENSITIVITY 1W/1m | 87 dB |
FREQUENCY RESPONSE | 37-500 Hz |
FREE AIR RESONANCE | 40 Hz |
VOICE COIL DIAMETER | 38 mm |
AIR GAP HEIGHT | 8 mm |
RATED POWER INPUT | 80W |
MAXIMUM POWER INPUT | 150 W |
FORCE FACTOR, BL | 13 TM |
MAGNET WEIGHT (28.5oz) | 808 g |
MOVING MASS | 45 g |
FERRO FLUID ENHANCED | No |
SUSPENSION COMPL. | 379.27 uMN-1 |
EFFEC.PISTON AREA | 0.022 M2 |
Levc | 0.715 mH |
Zo | 90.88 ohm |
X-max | 7 mm |
Vas | 25.68 Litr. |
Qts | 0.37 |
Qms | 3.94 |
Qes | 0.41 |
