- Order number: da-rs180-8
The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker... more
Product information "Dayton Audio RS180-8"
The Dayton Audio Reference Series sets a new standard of value in high-performance loudspeaker drivers. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, rubber magnet boot, and gold spring terminals.
Specifications
Impedance
8 ohms
Re
6.4 ohms
Le
0.73 mH @ 1 kHz
Fs
35.7 Hz
Qms
1.22
Qes
0.42
Qts
0.31
Mms
17.9g
Cms
1.12 mm/N
Sd
124.7 cm²
Vd
74.8 cm³
BL
7.82 Tm
Vas
24.4 liters
Xmax
6.0 mm
VC Diameter
38 mm
SPL
87.1 dB @ 2.83V/1m
RMS Power Handling
60 watts
Usable Frequency Range (Hz)
39 - 3,600 Hz
